8×8 Digital Audio Processor (Dante)
Categories: Open Architecture DSP Server
KYRO 88D Digital Audio Processor from the ERTHPOT KYRO product line is a compact 8×8 solution designed for professional audio and conferencing applications. Built on the ADI SHARC 21489@450MHz SIMD platform, it features a semi-open architecture, Ethernet connectivity, and an open user interface for easy device management. The processor provides 8 microphone/line inputs, 8 analog outputs, and 8×8 Dante network channels. Advanced features include Adaptive Echo Cancellation, feedback suppression, Auto Mixer Control, Automatic Gain Control, Audio Ducking, and Ambient Noise Compensation. With preset management, channel linking, grouping, RS-232, and UDP control, KYRO 88D is ideal for meeting rooms, classrooms, and conference spaces.
| Processor | ADI SHARC 21489@450 MHZ SIMD |
|---|---|
| Sampling rate/quantization bits | 48K/24bit |
| Number of analog input and output channels | 8x8 |
| Number of DANTE input and output channels | 8x8 |
| Input gain | 0/3/6/9/12/15/18/21/24/27/ 30/33/36/39/42/45/48 dBu |
| Phantom power | +48V/10mA max |
| Frequency response | ±0.5dB(20~20kHz) |
| Maximum level | +18dBu |
| THD+N | <-95dB @17dBu |
| Input dynamic range | 113dB |
| Output dynamic range | 113dB |
| Channel isolation @lkHz | 108dB |
| Input impedance (balanced connection) | 5.4ΚΩ |
| Output impedance (balanced connection) | 600Ω |
| System delay | <3ms |
| Working power supply | 110-240VAC 50/60Hz |
| Dimensions (width x depth x height) | 482 x 260 x 45mm |
| Shipping weight | 4KG |
