HD Video Conference Camera
Categories: PTZ Camera
The ACZ20X is specifically designed for the professional market, offering top-notch quality and performance with its large 1/2.8” sensor, to deliver crystal clear images with stunning detail. The 20X optical zoom with wide angle field of view allows for close-up shots without sacrificing image quality, making it perfect for capturing every moment with precision. It also boasts a sturdy and smooth robotics mechanism to ensure seamless movement and precise positioning, giving you the fle m xibility to capture the perfect shot every time. Whether you’re broadcasting a live event, conducting a conference, streaming live content, or recording a podcast, the ACZ20X is the perfect companion for any professional video capture.
| Lens | 20X Optical Zoom, f=5.2m(W)~104mm(T), F1.55~F3.13 |
|---|---|
| Image Sensor | SONY 1/2.8" CMOS |
| Pixels | 3.10 Megapixels, 2.07 Effective Megapixels |
| Scan Mode | Line by line |
| Digital Zoom | 16X |
| White Balance | Auto, Indoor, Outdoor, One Push, Auto Tracking, Manual |
| Minimum Illumination | 0.1 Lux @ (F1.5, AGC ON) |
| Shutter Speed | 1/50s ~ 1/10000s |
| Digital Noise Reduction | 2D&3D Digital noise reduction |
| Preset Position | 9 preset positions by IR remote controller, 255 preset positions by joystick controller or PC |
| POE | 802.3af (Optional) |
| Input Voltage | DC 12V |
| Input Current | Max.1.5A |
| Power Consumption | Max.18W |
| Operational Temperature | 0~40 |
| Storage Temperature | -10~6 |
| Camera Dimensions | (W)134*(D)174*(H)187 |
| Color | Black, White (Optional) |
| Weight | 1.2kg |
| Accessories | DC 12V power adapter, IR Remote, User manual, USB3.0 Cable, RS-232C Cable, Ceiling bracket, Wall bracket (Optional) |
• 1080P HD Resolution: Equipped with a SONY 1/2.8” Progressive CMOS sensor, it offers 2.07 Megapixels, supporting up to 1920×1080 resolution at 60fps.
• Abundant Outputs for Rich Application Scenarios: Supports simultaneous HDMI, 3G-SDI, LAN, and USB3.0 FHD 1080P output.
• Ultra-High Frame Rate: Video output frame rate can reach 1080P 60fps.
• Optical Zoom Can be Chosen: 20x optical zoom+16x digital zoom
• Low Light: The new CMOS sensor and 2D&3D Digital Noise Reduction effectively minimize image noise, even in ultra-low light, maintaining a clean and clear image with an S/N Ratio higher than 55dB.
• IR Pass-through: In addition to receiving signals from its dedicated remote control, it can also receive signals from users’ infrared remote controls and transmit them to the video conferencing terminal through the VISCA IN port.
• Multiple Video Compression Standards: Different interfaces support various video compression formats, including YUY2, MJPG, H.265, and H.264.
• Multiple Network Protocols: Support SRT, RTSP, RTMP, RTMPS, and NDI®|HX2 (optional), and other network protocols.
• Multiple Control Protocols: Supports VISCA (including VISCA Over IP), PELCO P/D, Onvif, and NDI® (optional) control protocols, with automatic identification.
• New generation AI human tracking algorithm: Features AI tracking and Auto-framing functions. (*Note: With AI intelligent tracking and automatic framing functions enabled, USB 3.0+HDMI+LAN support 1080p60 resolution output, 3G-SDI has no video output, and all three interfaces can output simultaneously.)
• Various Installation Methods: Supports desktop, ceiling, and wall installation.
